Name: Hamamatsu X Ray Source Designed for X Ray CT and In Line Inspection Applications
Brand: Hamamatsu
Price: 1 USD

Brand Name : Hamamatsu

Model Number : L11831-01

Place of Origin : JAPAN

MOQ : 1

Payment Terms : T/T

Packaging Details : carton

Target Material : Tungsten

Communication : Interface: RS-232C(9-pin D-sub connector)

Contact Now

Hamamatsu X-Ray Source for X-Ray CT and In-Line Inspection

90 kV Microfocus X-Ray Source

High-performance X-ray source designed for precision inspection applications requiring exceptional image clarity and resolution.

Applications

Applicable Objects

Key Features

Focal Spot Size: 15 μm (at 90kV)
5 μm focal spot of sealed type X-ray tube enables sharp, clear X-ray images even at high magnification
Easy Handling: Fully operable from external PC
Serial Port Control (RS-232C): Integrated package includes sealed X-ray tube, high-voltage power supply, and control function

Technical Specifications

X-Ray Control Unit
Function	Tube Voltage and Tube Current Preset / Auto Warm-up	-
Protection	Interlock	-
External Control	RS-232C	-
Applicable OS	Windows 2000 Professional, XP Professional	-
Computer Operating Conditions	CPU: Intel Pentium or Higher, Memory: 64MB or More	-

General Specifications
Input Voltage (DC)	+24	V
Power Consumption (Max.)	96	W
Operating Ambient Temperature	+10 to +40	℃
Storage Temperature	0 to +50	℃
Operating and Storage Humidity	Below 85% (No Condensation)	%
Weight	Approx. 10	kg
Conformance Standards	CE (EMC: IEC61326-1, Group 1, Class A)	-
Operation	Continuous	-
High Voltage Power Supply	Built-in	-

X-Ray Tube Specifications
X-ray Tube	Sealed Type	-
X-ray Tube Cooling Method	Convection Cooling	-
X-ray Tube Window Material/Thickness	Beryllium/150	μm
Target Material	Tungsten	-
Tube Voltage Operational Range	20 to 90	kV
Tube Current Operational Range	10 to 200 (8 W Max.)	μA
Maximum Output	8	W
X-ray Focal Spot Size	7 (5μm at 4W)	μm
X-ray Beam Angle (Coned)	39	degrees
Focus to Object Distance (FOD)	9.5	mm

Dimensional Outline

Dimensional Outline Diagram

Tube Current Operational Range

Tube Current Operational Range Chart

90 kV microfocus X-ray source
